TIMKEN BEARINGS
TIMKEN CYLINDRICAL ROLLER BEARINGS
| d D T | Rt | D1 | 1 | H E | r | Ca0 | Ca | ||||||
| mm in. | mm in. | mm in. | mm in. | mm in. | mm in. | mm in. | mm in. | mm in. | kN lbf. | kN lbf. | RPM | kg lbs. | |
| 60TPS125 | 152.400 6.0000 | 266.700 10.5000 | 66.675 2.6250 | 241.30 9.500 | 252.46 9.938 | 155.58 6.125 | 241.3 9.50 | 187.3 7.38 | 3.2 0.12 | 3300 738800 | 700 162900 | 1140 | 15.2 33.5 |
| 60TPS126 | 152.400 6.0000 | 292.100 11.5000 | 66.675 2.6250 | 342.90 13.500 | 277.81 10.938 | 155.58 6.125 | 265.1 10.44 | 187.3 7.38 | 3.2 0.12 | 4600 1032600 | 900 208300 | 1030 | 20.1 44.3 |
| 60TPS127 | 152.400 6.0000 | 317.500 12.5000 | 66.675 2.6250 | 431.80 17.000 | 303.21 11.938 | 155.58 6.125 | 287.3 11.31 | 190.5 7.50 | 3.2 0.12 | 5600 1252500 | 1100 240600 | 950 | 25.2 55.6 |
| 70TPS129 | 177.800 7.0000 | 266.700 10.5000 | 66.675 2.6250 | 206.38 8.125 | 251.62 9.906 | 180.80 7.125 | 242.9 9.56 | 206.4 8.12 | 3.2 0.12 | 2800 625400 | 600 140700 | 1140 | 12.7 27.9 |
| 70TPS130 | 177.800 7.0000 | 292.100 11.5000 | 66.975 2.6250 | 292.10 11.500 | 277.02 10.906 | 180.98 7.125 | 266.7 10.50 | 209.6 8.25 | 3.2 0.12 | 3900 886500 | 800 182100 | 1030 | 17.7 39.1 |
| 70TPS131 | 177.800 7.0000 | 317.500 12.5000 | 66.675 2.6250 | 390.53 15.375 | 302.42 11.906 | 180.98 7.125 | 288.9 11.38 | 209.6 8.25 | 3.2 0.12 | 5200 1180100 | 1000 224800 | 950 | 23.3 51.3 |
| 70TPS132 | 177.800 7.0000 | 374.650 14.7500 | 101.600 4.0000 | 390.53 15.375 | 353.22 13.906 | 180.98 7.125 | 335.0 13.19 | 228.6 9.00 | 6.4 0.25 | 7500 1692700 | 1700 371200 | 810 | 52.6 115.9 |
| 80TPS134 | 203.200 8.0000 | 323.850 12.7500 | 101.600 4.0000 | 215.90 8.500 | 302.42 11.906 | 207.96 8.188 | 292.1 11.50 | 238.1 9.38 | 6.4 0.25 | 4500 1016000 | 1100 251800 | 950 | 29.8 65.8 |
| 80TPS135 | 203.200 8.0000 | 374.650 14.7500 | 101.600 4.0000 | 304.80 12.000 | 353.22 13.906 | 207.96 8.188 | 336.6 13.25 | 263.5 10.38 | 6.4 0.25 | 6900 1558900 | 1500 343800 | 810 | 47.7 105.2 |
| 80TPS136 | 203.200 8.0000 | 428.625 16.8750 | 101.600 4.0000 | 495.30 19.500 | 404.02 15.906 | 209.55 8.250 | 382.6 15.06 | 266.7 10.50 | 6.4 0.25 | 9300 2091300 | 1900 423600 | 710 | 68.2 150.4 |
| 90TPS139 | 228.600 9.0000 | 374.650 14.7500 | 101.600 4.0000 | 304.80 12.000 | 353.22 13.906 | 234.95 9.250 | 339.7 13.38 | 263.5 10.38 | 6.4 0.25 | 6800 1524300 | 1500 333400 | 810 | 42.2 93.1 |
| 90TPS140 | 228.600 9.0000 | 428.625 16.8750 | 101.600 4.0000 | 495.30 19.500 | 404.02 15.906 | 234.95 9.250 | 385.8 15.19 | 266.7 10.50 | 6.4 0.25 | 9400 2115800 | 1900 422200 | 710 | 63.3 139.5 |
| 100TPS143 | 254.000 10.0000 | 428.625 16.8750 | 101.600 4.0000 | 425.45 16.750 | 404.02 15.906 | 260.36 10.250 | 387.4 15.25 | 292.1 11.50 | 6.4 0.25 | 8500 1905400 | 1700 384700 | 710 | 56.2 124.0 |
| 100TPS144 | 254.000 10.0000 | 479.425 18.8750 | 127.000 5.0000 | 508.00 20.000 | 454.82 17.906 | 260.36 10.250 | 435.0 17.12 | 304.8 12.00 | 6.4 0.25 | 12000 2702600 | 2500 556000 | 630 | 99.5 219.5 |
| 100TPS145 | 254.000 10.0000 | 530.225 20.8750 | 127.000 5.0000 | 609.60 24.000 | 505.62 19.906 | 260.36 10.250 | 481.0 18.94 | 336.6 13.25 | 6.4 0.25 | 15600 3512400 | 3000 670600 | 570 | 131.8 290.6 |
| 120TPS151 | 304.800 12.0000 | 479.425 18.8750 | 127.000 5.0000 | 390.53 15.375 | 454.82 17.906 | 311.15 12.250 | 438.2 17.25 | 346.1 13.62 | 6.4 0.25 | 10800 2423800 | 2200 500700 | 630 | 82.1 181.0 |
