NACHI Pillow Block Housings.

Plummer Block housings ease to constitute bearing units by using with self-aligning ball bearings or spherical roller bearings. NACHI Plummer Block housing design is
improved in term of accuracy, strength and rigidity.

Designations		Applicable parts								Y (Reference)
Designations		Self-aligning ball bearings	Spherical roller bearings	Nut	Locking washer	0il seal		Locating ring
Same Bore Type	Different Bore Type					0il seal		Locating ring
Same Bore Type	Different Bore Type					db side	de side	Designations	Q’ty
SN212	SN212C	1212	一	AN12	AW12X	GS16	GS12	SR110×8	2	26
		2212	22212EX					SR110×10	1	29
SN312	SN312C	1312	21312E	AN12	AW12X	GS16	GS12	SR130×12.5	2	31
		2312	22312EX					SR130×10	1	39
SN213	SN213C	1213	一	AN13	AW13X	GS17	GS13	SR120×10	2	28
		2213	22213EX					SR120×12	1	32
SN313	SN313C	1313	21313E	AN13	AW13X	GS17	GS13	SR140×12.5	2	33
		2313	22313EX					SR140×10	1	40
SN214	SN214C	1214	一	AN14	AW14X	GS18	GS15	SR125×10	2	28
		2214	22214EX					SR125×13	1	32
SN314	SN314C	1314	21314E	AN14	AW14X	GS18	GS15	SR150×13	2	34
		2314	22314EX					SR150×10	1	42
SN215	SN215C	1215	一	AN15	AW15X	GS19	GS16	SR130×8	2	30
		2215	22215EX					SR130×10	1	33
SN315	SN315C	1315	21315E	AN15	AW15X	GS19	GS16	SR160×14	2	36
		2315	22315EX					SR160×10	1	45
SN216	SN216C	1216	一	AN16	AW16X	GS20	GS17	SR140×8.5	2	32
		2216	22216EX					SR140×10	1	36
SN316	SN316C	1316	21316E	AN16	AW16X	GS20	GS17	SR170×14.5	2	39
		2316	22316EX					SR170×10	1	48
SN217	SN217C	1217	一	AN17	AW17X	GS21	GS18	SR150×9	2	34
		2217	22217EX					SR150×10	1	38
SN317	SN317C	1317	21317E	AN17	AW17X	GS21	GS18	SR180×14.5	2	41
		2317	22317EX					SR180×10	1	50
SN218	SN218C	1218	一	AN18	AW18X	GS22	GS19	SR160×16.2	2	35
		2218	22218EX					SR160×11.2	2	40
		一	23218E					SR160×10	1	46
SN219	SN219C	1219	一	AN19	AW19X	GS24	GS20	SR170×10.5	2	37
		2219	22219EX					SR170×10	1	43
