SKF Single rowAngular contactBallBearings 7322BEP

SKF single row angular contact ball bearings can accommodate axial loads in one direction only. This type of bearing is typically adjusted against a second bearing. Their bearing rings have an upper and a lower shoulder and are non-separable.

SKF BEARINGS various selection , welcome inquiry online or email me directly to : info@cmtgbearing.com.

SKF Single row angular contact ball bearings:

Designation	Principal dimensions			Basic load ratings		Speed ratings
				dynamic	static	Reference speed	Limiting speed
	d[mm]	D[mm]	B[mm]	C[kN]	C₀[kN]	[r/min]	[r/min]
7322 BEM	110	240	50	225	224	3 400	3 400
7322 BEP	110	240	50	225	224	3 400	3 200
7024 BGM	120	180	28	87.1	93	4 000	4 000
7224 BCBM	120	215	40	165	163	3 600	4 000
7224 BGAM	120	215	40	165	163	3 600	4 000
7224 BM	120	215	40	165	163	3 600	4 000
7324 BCBM	120	260	55	238	250	3 000	3 600
7324 BGAM	120	260	55	238	250	3 000	3 600
7324 BGBM	120	260	55	238	250	3 000	3 600
7226 BCBM	130	230	40	186	193	3 200	3 400
7226 BGAF	130	230	40	186	193	3 400	3 400
7226 BGAM	130	230	40	186	193	3 400	3 800
7226 BM	130	230	40	186	193	3 400	3 800
7326 BCBM	130	280	58	276	305	2 800	3 400
7326 BGAM	130	280	58	276	305	2 800	3 400
7326 BM	130	280	58	276	305	2 800	3 400
7028 BGM	140	210	33	114	129	3 400	3 400
7228 BCBM	140	250	42	199	212	3 000	3 600
7228 BGAM	140	250	42	199	212	3 000	3 600
7228 BM	140	250	42	199	212	3 000	3 600
7328 BCBM	140	300	62	302	345	2 600	3 000
7328 BGAM	140	300	62	302	345	2 600	3 000
7030 BGM	150	225	35	133	146	3 200	3 200
7230 BCBM	150	270	45	216	240	2 800	3 200
7230 BGAM	150	270	45	216	240	2 800	3 200
7330 BCBM	150	320	65	332	390	2 400	2 800
7330 BGAM	150	320	65	332	390	2 400	2 800
7232 BCBM	160	290	48	255	300	2 800	3 000
7232 BGAM	160	290	48	255	300	2 800	3 000
7332 BCBM	160	340	68	358	440	2 400	2 600

CMTG BEARING CO.,LIMITED. has been engaged in bearing industry for many years, we provide a wide selections of brands, including FAG bearing, SKF bearing,NSK bearing,Nachi bearing, TIMKEN bearing, THK Linear Guide and Linear Block …ect.

Bearing typies including standard bearing and non-standard bearings, linear bearings, automotive bearings, large bearings, railway bearings,spherical plain bearings, high temperature,super-precision bearings, as well as some rare types customized to your need.

Welcome inquiry.
